18E Lock Washer E106A-1 1 X X
18F #10-24 HN CF000010 1 X X
08-03-2009 RANGER ® 305D
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-492-F.2
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-492-F.2
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
