9C 5/16-18 x 1.00 HHCS
CF000062
2
X X X X
9D Plain Washer
S9262-121
2
X X X X
9E
Lock Washer
E106A-14
2
X X X X
9F
5/16-18 HN
CF000029
2
X X X X
9G Air Intake Hose
M20061
1
X X X X
9H Hose Clamp
S10888-29
2
X X X X
10A Solenoid Assembly, Idler
S20140-3
1
X X X X
10B 1/4-20 x .75 HHCS
CF000014
2
X X X X
10C Plain Washer
S9262-98
2
X X X X
10D Lock Washer
E106A-2
4
X X X X
10E 1/4-20 HN
CF000017
2
X X X X
10F In-Line Swivel
S22070
1
X X X X
10G Governor Ball Joint
S10623-2
1
X X X X
10H 1/4-28 x .625 HHCS
T8833-51
1
X X X X
10J 1/4-28 HN
CF000198
3
X X X X
11A Governor Arm Bracket
S25108
1
X X X X
11B 1/4-20 x .75 HHCS
CF000014
1
X X X X
11C Lock Washer
E106A-2
1
X X X X
11D Plain Washer
S9262-98
1
X X X X
11E 1/4-20 HN
CF000017
1
X X X X
13
Shutdown Solenoid (Supplied w/Engine)
(Note 1)
1
X X X X
14A Lift Bale Assembly
L11880
1
X X X X
14B 3/8-16 X .75 HHCS
CF000034
6
X X X X
14C Lock Washer
E106A-16
6
X X X X
15
Fuel Hose(9") (Not Shown) (Main Filter to Fuel Pump) T10642-256
1
X • • •
Hose Clamp (Not Shown)
T13777-5
2
X • • •
16
Fuel Hose (4") (Not Shown) (Pump to In-Line Filter)
T10642-67
1
X • • •
Hose Clamp (Not Shown)
T13777-5
2
X • • •
17
Fuel Hose (9") (In-line Filter to Engine) (Not Shown)
T10642-256
1
X X X X
Hose Clamp (Not Shown)
T13777-5
2
X X X X
18
Fuel Hose (17”) (Not Shown)
T10642-65
1
• X X X
(Main Filter to Mechanical Fuel Pump)
Hose Clamp (Not Shown)
T13777-5
2
• X X X
19
Fuel Hose (9”) (Not Shown) (Mechanical Pump to in-line Filter)
T10642-256
1
• X X X
Hose Clamp (Not Shown)
T13777-5
2
• X X X
02-06-2013
RANGER
®
305D
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-492-H.2
ITEM DESCRIPTION
PART NO.
QTY.
1 2 3 4 5 6 7 8 9
P-492-H.2
Note 1-See Kubota Parts List.
Supplied by Engine Manufacturer.
