Blower Baffle Assembly, Includes: G4097-9 1 X •
Blower Baffle Assembly, Includes: G4097-10 1 • X
1 Baffle G3862-1 1 X X
2 Warning Decal T13086-163 1 X X
3 Baffle S24624 1 X X
4 Heat Sink Holder S22168 3 X X
5 Thread Forming Screw (Cutting) S9225-17 3 X X
6A Thread Forming Screw (Cutting) S9225-17 3 X X
6B Plain Washer S9262-98 3 X X
6C Lock Washer E106A-2 3 X X
6D 1/4-20 HN CF000017 3 X X
7A Weld Control PC Board Assembly G4107-[ ] 1 X •
7A Weld Control PC Board Assembly G5507-[ ] 1 • X
7B Self Tapping Screw S8025-100 4 X X
8 Chopper Board Assembly L11845-[ ] 1 X X
9A Capacitor S13490-114 1 X X
9B Capacitor Bracket L9250 1 X X
10 Bushing T14614-1 1 X X
11A Resistor S10404-138 1 X X
11B Heat Sink Holder S22168 2 X X
11C Thread Forming Screw (Cutting) S9225-17 2 X X
11D Plain Washer S9262-98 2 X X
11E Lock Washer E106A-2 2 X X
11F 1/4-20 HN CF000017 2 X X
11G #10-24 x 7.50 RHS CF000191 1 X X
11H Plain Washer S9262-27 2 X X
11J Lock Washer E106A-1 1 X X
11K #10-24 HN CF000010 1 X X
12A Relay, DPDT 12-VDC AG-C100 S14293-14 1 X •
12A Relay, SPDT 12-VDC S14293-20 1 • X
12B Self Tapping Screw S8025-91 2 X X
12C Socket, Relay S14531-5 1 • X
13A Diode Bridge, 35A, 400V, FW 1PH T13637-6 2 X X
13B #10-24 x .75 RHS CF000072 2 X X
13C #10-24 HN CF000010 2 X X
13D Lock Washer E106A-1 2 X X
13E Plain Washer S9262-27 2 X X
14A Pull Coil PC Board Assembly L11768-[ ] 1 X X
14B Self Tapping Screw S8025-100 4 X X
15A Thread Forming Screw S9225-76 1 X X
15B Plain Washer S9262-27 2 X X
15C #10-24 HN CF000010 2 X X
15D Lock Washer E106A-1 1 X X
15E Lock Washer T9695-1 1 X X
16 Grommet S18543-5 1 X X
17 Thread Forming Screw (Cutting) S9225-68 1 X X
18A Resistor S10404-132 1 X X
18B #10-24 x 3.00 RHS CF000009 1 X X
18C Insulating Washer T4479-A 2 X X
18D Plain Washer S9262-27 1 X X
08-03-2009 RANGER ® 305D
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-492-F.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
