Lincoln Electric IM970 RANGER 305 D - Manual (Page 69)

1A Engine (M20062) (KUBOTA) NSS 1 X • • •
1A Engine (M20502) (KUBOTA) NSS 1 • X • •
1A Engine (M21504) (KUBOTA) NSS 1 • • X •
1A Engine (M22868) (KUBOTA) NSS 1 • • • X
1B Fan Coupling Hub - Kubota S25211 1 X X X X
1C Lock Washer E106A-14 3 X X X X
1D Metric Screw (M8 X 1.25 X 25) T14731-11 3 X X X X
1E Fan, Pusher (350mm) (Supplied w/Engine) (Note 1) 1 X X X X
1F Lock Washer E106A-2 4 X X X X
1G 1/4-20 x .75 HHCS CF000014 4 X X X X
1H Flat Washer (Not Shown) S9262-98 4 X X X X
2A Left Engine Foot L11885-2 1 X X X X
2B Right Engine Foot L11885-1 1 X X X X
2C Rubber Mounting T11991-3 2 X X X X
2D Thread Forming Screw S9225-26 4 X X X X
2E 3/8-16 x 1.25 HHCS T8833-62 2 X X X X
2F Lock Washer E106A-16 2 X X X X
2G Plain Washer S9262-120 2 X X X X
2H HHCS (M10 X 1.25 X 25) T14731-30 4 X X X X
2J Lock Washer S17400-1 4 X X X X
3A Muffler Asbly (Includes M20062-9 Gasket) G4247-1 1 X X X X
3B Exhaust Gasket (Supplied w/Engine) (M20062-9) (Note 1) 1 X X X X
3C M8 x 1.25 x 25mm Bolt (Supplied w/Engine) (Note 1) 4 X X X X
3D M8 Nut (Supplied w/Engine) (Note 1) 4 X X X X
3E Spring Washer (M8) (Supplied w/Engine) (Note 1) 4 X X X X
3F Flat Washer S9262-121 4 X X X X
3G Muffler Bracket S25496 1 X X X X
3H Thread Forming Screw S9225-26 4 X X X X
3J Spark Arrestor (Includes Fasteners) S20462 1 X X X X
3K Outlet Pipe Elbow M16980-1 1 X X X X
4A Inline Fuel Filter (Supplied w/Engine) (Note 1) 1 X X X X
6A Main Fuel Filter/Sedimenter (Supplied w/Engine) (Note 1) 1 X X X X
6B 5/16 -18 X 2.50 HHCS CF000187 1 X X X X
6C Lock Washer E106A-14 1 X X X X
6D 5/16HN CF000029 1 X X X X
7A Solenoid & Fuel Pump Bracket L11898 1 X X X X
7B Screw M8 X 1.25 20 HHCS T14731-3 2 X X X X
7C Lock Washer E106A-14 2 X X X X
7D Fuel Pump, Electric (Supplied w/Engine) (Note 1) 1 X • • •
7E 1/4-20 x .75 HHCS CF000014 2 X X X X
7F Plain Washer S9262-98 2 X X X X
7G Lock Washer E106A-2 2 X X X X
7H 1/4 x 20 HN CF000017 2 X X X X
7J Plain Washer S9262-121 2 X X X X
8A Adapter Fitting S25362-2 1 X X X X
8B 5/8 ID Drain Hose T10642-264 1 X X X X
8C Hose Clamp S10888-27 2 X X X X
8D Adapter Fitting S25362-1 1 X X X X
8E Oil Drain Valve S24662 1 X X X X
9A Air Cleaner Housing & Element M19801-1 1 X X X X
9B Air Cleaner Mounting Band S25230 1 X X X X
02-06-2013 RANGER ® 305D
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-492-H.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-492-H.1
Note 1-See Kubota Parts List.
Supplied by Engine Manufacturer.
NSS - Not Sold Separately
