C-1 ACCESSORIES C-1
FIELD INSTALLED OPTIONS /
ACCESSORIES
K957-1 HEAVY DUTY, TWO WHEEL TRAILER FOR
SMALL WELDERS
For road, off-road and in-plant and yard towing.
(For highway use, consult applicable federal, state
and local laws regarding requirements for brakes,
lights, fenders, etc.).Order:
K957-1 Trailer
K958-1 Ball Hitch
K958-2 Lunette Eye Hitch
K959-2 Fender & Light Kit
K965-1 Cable Storage Rack
K1789-1 ROLL CAGE - Gives added damage protection.
K1898-1 SPARK ARRESTOR
K704 ACCESSORY SET - Includes 35 ft. (10m) of
electrode cable and 30 ft. (9.1m) of work cable, head-
shield, work clamp electrode holder. Cables are rated
at 400 amps, 100% duty cycle.
K857 25 ft (7.6m) or K857-1 100 ft. (30.4m)
REMOTE CONTROL
Portable control provides same dial range as the out-
put control on the welder. Has a convenient 6 pin plug
for easy connection to the welder.
K2174-1 COLD WEATHER OPERATIONS KIT-
Provides starting aid and enhancement in extreme
cold weather. Includes radiator grill cover, oil pan
heater, coolant Lester and all hardware required for
installation.
K802-N POWER PLUG KIT
Provides four 120 volt plugs rated at 20 amps each
and one dual voltage, full KVA plug rated at 120/240
volts, 50 amps.
K802-R POWER PLUG KIT
Provides four 120 volt plugs rated at 15 amps each
and one dual voltage, full KVA plug rated at 120/240
volts, 50 amps.
T12153-9 50 AMP, 120/240 V POWER PLUG
K1816-1 FULL KVA ADAPTER KIT
Plugs into the 120/240V NEMA 14-50R receptacle on
the case front (which accepts 4-prong plugs) and
converts it to a NEMA 6-50R receptacle, (which
accepts 3-prong plugs.) For connection of Lincoln
equipment with NEMA 6-50R plug.
TIG Welding
K1783-9 TIG Torch PTA-26V (25ft.)
K963-3 Hand Amptrol
K870 Foot Amptrol
KP509 Magnum Parts Kit
Spool Gun
K1692-2 Prince XL Spool Gun (25ft.)
K487-25 Magnum Spool Gun
K488 Magnum Control Module
K691-10 Input Cable)
RANGER® 305D
