Lincoln Electric IM970 RANGER 305 D User Manual
Page 55
1
Case Front
G3860-4
1
X • •
1
Case Front
G3860-8
1
• X X
2A
Output Terminal Kit, Includes:
T14166-9
2
X X X
Self Tapping Screw (Not Shown)
S8025-91
4
X X X
Output Stud Nut
T3960
2
X X X
3
Circuit Breaker Cover
M19161
1
X • •
4
Receptacle Cover
M18861
1
X X X
5A
Receptacle, Single
S18907-2
1
X X X
5B
Lock Washer (Not Shown)
T9695-3
4
X X X
5C #8-32 HN (Not Shown)
CF000042
4
X X X
6
Receptacle, Gasket
S21088
2
X X X
7
Cover Receptacle
M16996
2
X X X
8A
Receptacle, Duplex, GFCI
S24410-1
2
X X X
8B
Thread Forming Screw (Cutting)
S9225-63
4
X • •
8B
Thermoplastic Screw
S24738-3
4
• X X
8C Speed Nut
T11525-1
4
X X X
8D GFCI Cover
L13286
2
X X X
8E
Mounting Bracket
S27167
2
X X X
8G Receptacle Seal (Not Shown)
S27176
2
X X X
9
1/4-20 HJLN
T9187-1
1
X X X
10
1/4-20 HN
CF000017
1
X X X
11
Self Tapping Screw
S8025-96
4
X X X
12
Connector Cap
S17062-11
1
X X X
13
Circuit Breaker Decal
S24672-2
1
X • •
14
Connector Cap
S17062-10
1
X X X
15A Shunt & Lead Assembly
S24097-3
1
X X X
15B 1/2-13 x .875 HHCS (Not Shown)
CF000344
2
X X X
15C Plain Washer (Not Shown)
S9262-1
2
X X X
15D Lock Washer (Not Shown)
E106A-15
2
X X X
16A RF-Bypass Filter Assembly
S24982
1
X X X
16B Flat Washer (Not Shown)
S9262-27
1
X X X
16C Lock Washer (Not Shown)
E106A-1
1
X X X
16D #10-24 HN (Not Shown)
CF000010
1
X X X
17
Harness Assembly (Not Shown)
G4244-2
1
X X •
17
Harness Assembly (Not Shown)
G4244-4
1
• • X
18
Connector & Lead Assembly, Includes:
M19685-3
1
X X X
18A
Receptacle
S12021-70
1
X X X
18B
Receptacle
S12021-68
1
X X X
20A Circuit Breaker - 50A,250VAC
T12287-19
2
X • •
20B Circuit Breaker - 20A,250VAC, 50VDC
T12287-38
2
X X X
20C Sealing Boot (Not Shown)
S22061-2
2
• X X
21
Circuit Breaker-15A,250VAC,50VDC
T12287-22
2
X • •
22A Circuit Breaker-15A, 250VAC, 50VDC
T12287-37
2
• X X
22B Sealing Boot (Not Shown)
S22061-2
2
• X X
23A Circuit Breaker-50A, 2-Pole, Includes 28B
M20585
1
• X X
23B
Circuit Breaker Cover Seal
S24911-2
1
• X X
23C Sems Screw (Not Shown)
T10082-30
4
• X X
23D Lock Washer (Not Shown)
T4291-A
4
• X X
24A Thread Forming Screw
S9225-76
3
X X X
24B Plain Washer (Not Shown)
S9262-27
6
X X X
24C #10-24 HN (Not Shown)
CF000010
6
X X X
04-12-2010
RANGER
®
305D
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-492-C.1
ITEM DESCRIPTION
PART NO.
QTY.
1 2 3 4 5 6 7 8 9
P-492-C.1
NSS - Not Sold Separately
