Curt-O-Matic
Emergency Ventilation System
HIRED-HAND, INC. • 1733 Co Rd 68 • Bremen, AL 35033 · Phone 256-287-1000 • Fax 256-287-2000
Manual Part No. 4802-0103 rev 10-02 Page 4 of 4
CM-2 PRODUCT NUMBERS
Part # Model Description Electrical
6608-0100 CM-2-120-K-0 CM-2 120V 50/60 Hz 120v, 50/60 Hz
6608-0101 CM-2-120-K-S CM-2 120V 50/60 Hz, Single with T-Stat Assy 120v, 50/60 Hz
6608-0102 CM-2-120-K-D CM-2 120V 50/60 Hz, Double with T-Stat Assy 120v, 50/60 Hz
6608-5005 CM-2-208-X-S CM-2 208V 50/60 Hz, Single with T-Stat Assy 208v, 50/60 Hz
6608-5006 CM-2-208-X-0 CM-2 208V 50/60 Hz 208v, 50/60 Hz
6608-0105 CM-2-240-X-0 CM-2 240V 50/60 Hz 240v, 50/60 Hz
6608-0106 CM-2-240-X-S CM-2 240V 50/60 Hz, Single with T-Stat Assy 240v, 50/60 Hz
6608-0107 CM-2-240-X-D CM-2 240V 50/60 Hz, Double with T-Stat Assy 240v, 50/60 Hz
CM-3 PRODUCT NUMBERS (Used with Alert Alarm III, Farm Hand Alert Alarm, or other Systems)
Part # Model Description Electrical
6608-0110 CM-3-120-K-0 CM-3 120V 50/60 Hz 120v, 50/60 Hz
6608-0113 CM-3-120-K-S CM-3 120V 50/60 Hz, Single with T-Stat Assy 120v, 50/60 Hz
6608-0114 CM-3-120-K-D CM-3 120V 50/60 Hz, Double with T-Stat Assy 120v, 50/60 Hz
6608-0115 CM-3-240-X-0 CM-3 240V 50/60 Hz 240v, 50/60 Hz
6608-0118 CM-3-240-X-S CM-3 240V 50/60 Hz, Single with T-Stat Assy 240v, 50/60 Hz
6608-0119 CM-3-240-X-D CM-3 240V 50/60 Hz, Double with T-Stat Assy 240v, 50/60 Hz
Accessories:
Part # Model Description
1503-1508 CBL SJT 18-3 Black Cable, 18 AWG, 3 Conductor
6450-1220 /Kit IK CM Single Installation kit for CM Single
3005-0102 T-STAT, T19SB-1C SS single SPDT Stainless Steel Thermostat
3005-2130 TSTAT, T19PC-3C C/F Liquid Tight Water-Tight Thermostat
6614-2290 TSTAT Assy, T19PC-3C 20’ PBC F/C Thermostat Assembly w/Cord for 120v only
Hardware Parts List:
Part # Description Quantity
(for SINGLE Kit)
Quantity
(for DOUBLE Kit)
6450-1220 Curt-O-Matic Single Kit ↓ All parts below ↓
6450-1002 Curt-O-Matic Double Kit ↓ All parts below ↓
6408-2228 or
1030-1383 Winch Handle J-Hook, ¾” 1 2
0404-1026 Lever Winch Release 1 2
1003-1463 Fender Washer, 3/16 (for Lever) 2 4
1004-1386 Screw, Hex, 10-12 x 1 ( for Lever & CM Mounting) 3 4
6408-1223 Cable Assy 1/16 x 5 ft. 1 Assembly 2 Assemblies
1031-1486 Wire Rope/Cable, 1/16 – 1 x 7 1 @ 5 ft. 2 @ 5 ft./ea
1015-1472 Swedge 1/16 (Crimp Sleeve for Wire Rope) 2 4
1004-1397 Lag Screw Eye, ¼ x 1½ (Eye Cable Guide) 2 6
1006-1501 Chain 1 @ 4 ft. 2 @ 4 ft./ea
1012-1467 Quick Link, ¼ 1 2
1015-1469 Cable Clamp, 1/8 1 1
1004-1392 Lag Screw, 3/8 x 2”, Hex 1 1
1004-1222 Screw Hook, 8-15 x 2 round bent 1 1
1001-1456 3/8-16, Hex Nut (for house Corner Brkt.) 1 1
3006-1535 Wire Con. Nut, Blue (for CMIII Switch Hookup) 3 3
