Hired-Hand Emergency Back-Up and Alarms: AVD-45b Automatic Voice Dialer User Manual
Page 14
- 14 -
8. The AVD-45b will sequentially dial the programmed Locations (1-4). If there is no number stored in a
location, it will be skipped. The OGM will be delivered when the AVD-45b receives an answer. (The
OGM will not be played through the speaker.) For pager numbers, the pager code will be transmitted
instead of an OGM.
9. The AVD-45b will automatically go through the next programmed Location repeating the same process.
The AVD-45b is now ready for operation.
Utilizing the EEPROM and CPU memory cell components, the AVD-45b will retain its’ memory in
the event of a power loss. The internal 9-volt alkaline battery will provide stand by power for
approximately 4 hours of operation. If more battery backup is needed, an optional rechargeable power pack
(USP part# PP-1 or
PB12P Combination AC Adaptor/Rechargeable battery
) is available and plugs into
the AVD-45b, providing up to 24 hours of stand by power.
