Part No. 4801-0150 Rev 8-04 Farm Hand Swine Finisher 5 Stage 18 of 32
11.2 Connecting Equipment Directly to the Controller
Warning: Do not connect more than 12 amps of load to a single stage!
Warning: Check that the stage jumpers are removed when connecting a load
directly to the controller.
Note: Hired-Hand, Inc. recommends the use of an external contactor or relay
panel to drive equipment.
5 4 3 2 1
STAGES OUT
Inset B
5 4 3 2 1
IN
STAG
ES
Inset A
AL
AR
M N
.O .
AL
AR
M N .C .
5 4 3 2 1
IN
STAGES
3
2
1
SENSORS
+12V SI G N AL
GN
D
RE
T
HO
T L1 L2
EAR
T H
GND LO HI 5 4 3 2 1 FAN
2
FAN
1 IN
VAR FANS STAGES OUT
SWX1
J5
J4
J3
J2
PRESSURE AC POWER HH NET
Curtain 1 Curtain 2
Cl o s e
Op
e n
Ho
t
Cl o s e
Op
e n
Ho
t
Signal Signal
Inset A
Inset B
Swine Finisher
Common from
Relay Panel
To Relay Panel
Stage 1
Stage 2
Stage 3
Stage 4
Stage 5
Remove stage jumpers if
using a separate power
supply for each stage.
