Page 7
Part No. 4801-5042 Rev 9/99 PT Controller 5
10. Control Signals for Models with Timer
10.1 Connection of Thermostat
10.2 Connection to Stages for Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Hot
IN
Thermostat/Control
L1
Power Supply
L2
GND
Hot
IN
UNIT 1
UNIT 2
IN
OUT
IN
OUT
HEAT
STAGE
COOL
STAGE
NOTE: Two types of
thermostats can be used, a
Single Stage or Two Stage
