Hired-Hand Electro Mechanical Controls (Relay-Switches): PHOTOHELIC POWER VENT User Manual
Page 9
Part No. 4801-1206
Photohelic Power Vent
7
9.4 Photohelic 120 Volt (9-Wire)
9.5 Photohelic 240 Volt (9-Wire)
120
Volt
WHT
BLK
GRN
1 2 3 4 5
8 9 10 11 12
6
8 Connector
Wire From
Power Unit
White
Brown
Red
Blue
Orange
Black
Green
Yellow
To reverse wiring and
closing directions
switch, Top wires on
terminal as shown.
5 6 7 8
For Optional PV-R2 Relay Control
(Terminals 10, 11, & 12 Connect To
Terminals 10, 11 & 12 In PV-R2 Control)
1 2 3 4 5
8 9 10 11 12
6
120
Volt
WHT
BLK
GRN
White
Brown
Red
Blue
Orange
Black
Green
Yellow
8 Connector
Wire From
Power Unit
To reverse wiring and
closing directions
switch, Top wires on
terminal as shown.
5 6 7 8
For Optional PV-R2 Relay Control
(Terminals 10, 11, & 12 Connect To
Terminals 10, 11 & 12 In PV-R2 Control)
Black
Red
Ye
llo
w
