Internal wiring diagrams, schematics, etc, 3 photohelic to rollseal tube motors, 1 photohelic 120 volt – Hired-Hand Electro Mechanical Controls (Relay-Switches): PHOTOHELIC POWER VENT User Manual
Page 7: Rollseal tube motor
Part No. 4801-1206
Photohelic Power Vent
5
1
2
3
4
5
6
OPE
N
CL
O
S
E
Hot
IN
L1
Power Supply
L2
GND
OPE
N
CL
O
S
E
Hot
IN
UNIT 1
UNIT 2
7
8
9
RED
CLOSE
WHITE
GREEN
GROUND
NEUTRAL
HOT
110 VAC
POWER SUPPLY
HOT IN
OPEN
BLACK
ROLLSEAL
TUBE MOTOR
*If the motor has to turn
clockwise for the fabric to
open, place the black wire
on close and the red wire
on open.
*If the motor has to turn
counter-clockwise for the
fabric to open, place the
red wire on close and the
black wire on open.
8.3 Photohelic to Rollseal Tube Motors
9. Internal Wiring Diagrams, Schematics, etc.
9.1 Photohelic 120 volt
3021-1560
3001-2863
3006-1560
3015-2884
3015-2884
3006-1560
3001-2864
