Ultra Start 72 Series - Manual (Page 18)

SYSTEM PROGRAMMING - Menu 1
PAGE 18
INSTALL MANUAL
PROGRAM MODE
1 CHIRP
1 CHIRP
2 CHIRPS
CHANGE SETTING 1 -
GOTO SETTING 2 - PRESS & RELEASE THE VALET SWITCH PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
SETTING 1- VALET SETTINGS
THE HORN WILL CHIRP 1 TIME WHEN SETTING 1 IS SELECTED
1 CHIRP PRESS
1 TIME
2 CHIRPS
1 CHIRP
1X
CHANGE SETTING 2 -
GOTO SETTING 3 - PRESS & RELEASE THE VALET SWITCH PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
SETTING 2-PARK LIGHT OUTPUTS
THE HORN WILL CHIRP 2 TIMES WHEN SETTING 2 IS SELECTED
2 CHIRPS PRESS
1 TIME
2X
SETTING 3-HORN OUTPUT
THE HORN WILL CHIRP 3 TIMES WHEN SETTING 3 IS SELECTED
3 CHIRPS PRESS
1 TIME
3X
CHANGE SETTING 3 -
GOTO SETTING 4 - PRESS & RELEASE THE VALET SWITCH PRESS & HOLD THE VALET SWITCH UNTIL THE HORN CHIRP(S)
2 CHIRPS
3 CHIRPS
CON'T ON NEXT PAGE
SETS OPTION 1 – 30 SECOND- The park light output will flash for all functions and
will stay active for 30 seconds when unlock is pressed.
SETS OPTION 2 – NORMAL OPERATION- The park lights will flash for all
functions. (DEFAULT)
SETS OPTION 1 – SECURE- The LED/ Program Switch must be held for 15 seconds
to place the system into Valet Mode.
SETS OPTION 2 – STANDARD- The LED/ Program Switch must be held for 5
seconds to place the system into Valet Mode. (DEFAULT)
SETS OPTION 1 – SHORT OUTPUT- The HORN output will activate for 5ms when a
function is preformed.
SETS OPTION 2 – LONG OUTPUT- The HORN output will activate for 50ms when a
function is preformed.
SETS OPTION 3 – NORMAL OUTPUT- The HORN output will activate for 10ms
when a function is preformed. (DEFAULT)
ON/OFF - ON/OFF - ON
(Leaving the key ON)
IGNITION KEY
Press and release 1 time
PROGRAM SWITCH
1 CHIRP
Confirming
Program Mode
HORN CHIRP
Press UNLOCK
Button to
Select Menu 2
REMOTE BUTTON
ENTERING PROGRAM MODE 2
72 SERIES
