Z87H3-AX EXTREME (GOLDEN) USER MANUAL
Chapter 1
3
• AMI BIOS with 64 x 2 Mb SPI Flash ROM
- Supports Plug and Play
- Supports ACPI & DMI
- Supports S1 / STR (S3) /STD (S4)
- Supports Hardware monitor
- Audio, LAN, can be disabled in BIOS
- F7 hot key for boot up devices option
- Supports Over-Clocking
- Supports Dual Display
- Supports EZ BIOS
- Supports Multi-Language
- Dual BIOS System BIOS
Form Factor • ATX Size, 305mm x 244mm
• 1 x 24-pin ATX Power supply connector
• 1 x 8-pin ATX Power supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x 3-pin PWR_FAN connector
• 1 x 3-pin NB_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
(F_USB1 supports EZ charger function)
• 3 x USB 3.0 headers support additional six USB 3.0 ports
• 6 x Serial SATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x Buzzer
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x ME unlock header
• 1 x Debug post LED
• 1 x Power on button *
• 1 x Reset button *
• 1 x 80P Switch button *
• 1 x Quick OC button *
• 1 x BIOS set button *
• 1 x ROM Backup button *
• 1 x Easy Measure Point connector
Internal I/O
Connectors &
Headers
• ECS Exclusive AP: Supports eBLU * 1 /eDLU/eOC & eSF * 1 /EZ
Charger * 1
• 3rd Party Bundled software: Cyberlink Media Suite * 2 /Norton * 2 /
Muzee * 2 /Creative SBX studio * 2
AP/Bundled
Software
Support
Note: * 1 Microsoft .NET Framework 3.5 is required.
* 2 Free bundle software including ECS DVD: Cyberlink/Norton/
Muzee/Sound Blaster Cinema or Creative SBX studio.
Note: * These buttons will be introduced at the end of this chapter.
