SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (AHCI Mode)
Use this item to select SATA mode.
SATA Port 1~5/mSATA (Not Present)
This motherboard supports five SATA channels and one mSATA channel, and each
channel allows one SATA/mSATA device to be installed. Use these items to configure
each device on the SATA/mSATA channel.
Press to return to the Advanced Menu page.
External SATA Port6 & eSATA (AHCI Mode)
Use this item to select external SATA port6 & eSATA mode.
Determines how SATA
controller(s) operate.
Main Advanced Chipset M.I.B. X Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
SATA Configuration
SATA Mode AHCI Mode
External SATA Port6 & eSATA AHCI Mode
SATA Port1
Not Present
Spin Up Device
Disabled
External SATA Disabled
SATA Port2
Not Present
Spin Up Device
Disabled
External SATA Disabled
SATA Port3
Not Present
Spin Up Device
Disabled
External SATA Disabled
SATA Port4
Not Present
Spin Up Device
Disabled
External SATA Disabled
SATA Port5
Not Present
Spin Up Device
Disabled
External SATA Disabled
mSATA
Not Present
Spin Up Device
Disabled
External SATA Disabled
