Z87H3-AX EXTREME (GOLDEN) USER MANUAL

Chapter 1

7

The above port definition can be changed to audio input or audio output by
changing the driver utility setting.

A: Center & Woofer

C: Rear Headphone

B: Rear out & Line in

D: Front/Stereo out

-

E: Mic/Line in

7. Optical SPIDF Output port
This jack connects to external optical digital audio output devices.

8. USB 3.0 Ports
Use the USB 3.0 ports to connect USB 3.0 devices.

9. HDMI Port
You can connect the display device to the HDMI port.

10. eSATA 6Gb/s Port
Use this port to connect to external SATA boxes or Serial ATA port multipliers.

11. USB 2.0 Ports
Use the USB 2.0 ports to connect USB 2.0 devices.
