Z87h3-ax extreme (golden) user manual, Chapter 2 – Elitegroup Z87H3-AX GOLDEN (V1.0) User Manual
Page 17
Chapter 2
11
Z87H3-AX EXTREME (GOLDEN) USER MANUAL
D. Rotate the load plate onto the package IHS (Intergraded Heat
Spreader). Engage the load lever while pressing down lightly onto the
load plate. Secure the load lever with the hook under retention tab. Then
the cover will flick automatically.
Please save and replace the cover onto the CPU socket if processor is
removed.
