Z87H3-AX EXTREME (GOLDEN) USER MANUAL
Chapter 1
5
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1150 socket for Intel® 4
th
Generation Core
TM
Family Processors
2. CPU_FAN 4-pin CPU cooling fan connector
3. DDR3_1~4 240-pin DDR3 Module slots
4. EZM1 Easy Measure Point connector
5. ATX_POWER Standard 24-pin ATX power connector
6. RST_BTN Reset switch *
7. PWR_BTN Power on switch *
8. NB_FAN1 North Bridge cooling fan connector
9. BZ Buzzer
10. POST POST Error Code LED *
11. 80P_SW 80P switch button
12. SATA3_1~6 Serial ATA 6Gb/s connectors
13. QUICK_OC Quick OC button
14. CASE Case open header
15. BIOS_SET BIOS set button
16. ME_UNCLOCK ME Unlock header-for factory use only
17. F_PANEL Front panel switch/LED header
18. USB3F1~3 Front panel USB 3.0 headers
19. F_USB1~2 Front panel USB 2.0 headers (F_USB1 supports EZ Charger function)
20. COM Onboard serial port header
21. F_AUDIO Front panel audio header
22. PCIEX16_T PCI Express slot for graphics interface (runs at x4 mode)
23. ROM_BACKUP ROM Backup button
24. PCI 32-bit Add-on card slot
25. MINIPCIE Mini-PCI Express x1 slot
26. PCIEX16_3 PCI Express slot for graphics interface
27. PCIE1 PCI Express x1 slot
28. PCIEX16_1~2 PCI Express slots for graphics interface
29. PWR_FAN 3-pin power cooling fan connector
30. SYS_FAN 3-pin system cooling fan connector
31. ATX12V 8-pin +12V power connector
