Chapter 3
Z87H3-AX EXTREME (GOLDEN) USER MANUAL
59
Main Advanced Chipset M.I.B. X Boot Security Exit
The selection of Memory
Profiles which impacts
memory sizing behavior.
 Memory Configuration
Scroll to this item to view the following screen:
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Memory Information
Memory RC Version 1.3.0.0
Memory Frequency 1333 MHz
Total Memory 4096 MB (DDR3)
Memory Profiles Automatic
Memory Frequency 1333
Timing Default Current Target
tCL 9 9 9
tRCD 9 9 9
tRP 9 9 9
tRAS 24 24 24
NMode 1 1 Auto
tWR 10 10 10
tRFC 74 74 74
tRRD 4 4 4
tWTR 5 5 5
tRTP 5 5 5
tCWL 7 7 7
tREFI 5200 5200 5200
tFAW 20 20 20
tWRPRE 21 Auto
tCPDED 1 Auto
tPRPDEN 1 Auto
OdtReadDelay 2 Auto
tCKE 4 Auto
tCCD 4 Auto
tWPRE 1 Auto
tRPRE 1 Auto
tRDRD 4 Auto
tRDRD_dr 6 Auto
