PIN8000/PIN8010 Operation and Maintenance Manual
7.0
Specifications
Temperature Range:
Operating Temp:
+40° to +122°F (+4.4° to +50.0° C)
Storage Temperature: 0° to +185° F (–17.8° to +85°C)
Pressure Media:
Dry gaseous nitrogen, standard
Optional External Pressure Cylinder:
Capacity:
83.3 ft
3
N
2
@ 2,216 PSIG
Volume:
960 in
3
Rating:
2,216 psig
Test Pressure:
3,694 psig
Material:
Aluminum
Regulated Pressure Gauge:
Size:
2-1/2 in. diameter
Range:
0–3,000 PSIG
Test Pressure:
4,500 PSIG
Accumulator and Output Pressure Gauges:
Size:
2-1/2 in. diameter
Range:
0–15,000 PSIG
Test Pressure:
22,500 PSIG
Over-pressure Rupture Disk:
Rating:
3,000 PSIG, nominal
Type:
Stainless steel outer case
Pressure Media Filter:
Rating:
20 microns, Output (Test) Ports and
Input Port
40 microns, Output (Test) Port Hose
Type:
Field replaceable
Orion 3A Control Valves:
Type:
Micro-metering with positive shut off,
adjustable stop and replaceable seat,
non-destructible
Vernier Mechanical
Rotation:
16 turns, nominal
Adjustable Sensitivity: 0.0005 PSI, minimum
Vernier Torque:
Finger-tip adjust to 10,000 PSI
Material:
Aluminum knobs, black anodized
All other parts 300 series stainless
steel
Internal Piping:
Tubing:
1/8 in. O.D., 0.035 in. wall thickness,
seamless Cu.
1/4 in. O.D., 0.035 and 0.065 in. wall
thickness, seamless 304 Stainless
Steel
Couplings:
Stainless Steel, Swagelok type
Input Port:
Style:
1/4" 37° AN flare male
Pressure Rating:
2216 PSIG connected
Material:
300 series Stainless Steel
Output (Test) Ports:
Style:
Quick-disconnect type
Pressure rating:
10000 PSIG minimum, connected or
disconnected
Quantity supplied:
Two Output Quick-disconnects
(one, p/o output pressure hose)
Vent Port:
Style:
1/4" 37° AN male
Pressure Rating:
10,000 PSIG
Material:
300 series Stainless Steel
Pressure Hoses:
Quantity Supplied:
Two; one input, one output
Length:
4 ft. nominal, input hose
5 ft. nominal, output hose
Style:
Input hose - Nylon-lined core tube with
synthetic fiber braid and polyester
cover. Fitted with CGA-580 (Brass)
nipple fitting on one end and 1/4" 37°
female AN swivel pressure fitting on
opposite end.
Output hose - Nylon-lined core tube
with synthetic fiber braid and
polyurethane cover. Fitted with
quick-disconnect plug (St Stl) on one
end and 1/4" 37° female AN swivel
tube coupling on the other.
Condec REG1000 Regulator:
Type:
Single stage, self-venting, non-bleed
Pressure Rating:
3,000 PSIG max. inlet
Carrying Case PIN8000 only:
Type:
Aluminum case with latched cover and
handle
Material thickness:
0.090 in., nominal
Finish:
Enamel paint, textured finish
Color:
Gray
Control Panel:
Material:
Aluminum (5052-H32)
Thickness:
0.125 in
PIN8000 Finish:
Gray enamel paint with black
silkscreen nomeclature
PIN8010 Finish:
Dark Tan enamel paint with black
silkscreen nomenclature
Physical Specifications:
Weight:
46 lbs including all hoses and cables
PIN8000 Case Dim’s: 11" wide x 18" long x 11.5" high
PIN8010 Case Dim’s: 19" wide x 8.1" deep x 10.5" high
(Case Dimensions excluding front handles).
