PIN8000/PIN8010 Operation and Maintenance Manual
6.0
Options and Replacement Kits
Orion 3A O-Ring Replacement Kit (Data Sheet # 65308):
•
Fluorocarbon “Viton” (standard)...........................................................PN 55277
•
Nitrile Buna-N.......................................................................................PN 58499
•
Ethylene-Propylene ...............................................................................PN 58506
•
Silicone..................................................................................................PN 58509
•
Neoprene ...............................................................................................PN 58515
Note
A small coating of fluorinated Krytox grease, (PN 55593), should be applied to both sides of the O-ring prior to
installation.
•
Pressure Trap (Data Sheet # 58596)......................................................PN 58478
•
Output (Test) Port Quick-Disconnect Hose Fitting Male Coupling
Body, other end 7/16-20 Male, with Internal 40 Micron Filter
(standard, requires Cheat Seal PN 54854) ............................................PN 55542
•
Output (Test) Port Quick-Disconnect Fitting Male Coupling Body,
other end 1/4-18 NPT Female, with Internal 40 Micron Filter (may
be used to connect DPDG Gauge to Output Port).
see Figure 6-4 on page 31. ....................................................................PN 151017
•
Output (Test) Port Quick-Disconnect Fitting Male Coupling Body,
other end 1/4-18 NPT Female, no Filter (may be used to connect
DPDG Gauge to Output Port). See Figure 6-5 on page 31. ..................PN 151019
•
Five-Foot Hose with CGA-580 Male fitting, both ends, for use when
filling optional External Pressure Cylinder PN 59533..........................PN 150613
•
Input Port Hose Nitrogen Bottle Mating fitting (for connecting
External Pressure Cylinder PN 59533 to Internal Port, (one each of the following)
Cheat Seal Pad...................................PN 54854
Hose Adapter fitting ..........................PN 60803
CGA-580 Nipple ...............................PN 57150
CGA-580 Nut ....................................PN 57154
Note
For Input Port Quick-Disconnect Female Hose fitting assembly instructions see Section 4.2.17 on page 19.
Output (Test) Port Hose, with Quick-Disconnect Male fitting:
•
5' Long...................................................................................................PN 55280
Input Port Hose, with Nitrogen Bottle Mating fitting:
•
4' Long...................................................................................................PN 55360
•
10' Long.................................................................................................PN 55366
•
15' Long.................................................................................................PN 55369
•
20' Long.................................................................................................PN 55375
External Pressure Aluminum Cylinder with Shut-off Valve, Rupture Disk and
Carrying Handle, 83.3 cu ft. 3694 Test Pressure, 2216 PSI Service Pressure....PN 59533
