6 PIN8000/PIN8010 Operation and Maintenance Manual
4.2.1 Panel/Chassis Removal and Installation
PIN8000 Removal
Tools required: Phillips screwdriver
1. Loosen and remove the 10 screws (PN 14862) which secure the panel assembly to the enclosure.
2. Lift the panel and chassis by first grasping the regulator knob and output (test) port; and second, grasping
under the panel edges. Tilt the panel at an angle by lifting the right side before the left side as you face
the panel. Ensure that the wire harnesses do not catch and snag.
3. Gently set the panel/chassis assembly on a bench top. It can be rested on the panel bottom with the
accumulator supported by a screwdriver handle.
PIN8000 Installation
Tools required: Phillips screwdriver
1. Lift the panel and chassis by first grasping the regulator knob and output (test) port.
2. Gently place the panel/chassis assembly into the enclosure. Tilt the panel at an angle by lifting the right
side before the left side as you face the panel. Ensure that the wire harnesses do not catch and snag.
3. Align the mounting holes and install the 10 screws (PN 14862) which secure the panel assembly to the
enclosure.
PIN8010 Removal
Tools required: Phillips screwdriver
1. Loosen and remove the 14 screws (PN 14861) from the top, bottom, and sides which secure the panel
assembly to the enclosure. Loosen and remove the three screws (P/N 14861) from the rear of unit which
secure the enclosure to the output (test) port/AC input/input port panel.
2. Lift the panel and chassis by grasping the handles located on the front of the rack-mountable panel.
Ensure that the wire harnesses do not catch and snag.
3. Gently set the panel/chassis assembly on a bench top. It can be rested on the panel bottom with the
accumulator supported by a screwdriver handle.
PIN8010 Installation
Tools required: Phillips screwdriver
1. Lift the panel and chassis by grasping the handles located on the front of the rack-mountable panel.
2. Gently place the panel/chassis assembly into the enclosure. Ensure that the wire harnesses do not catch
and snag.
3. Align the mounting holes and install 14 screws (PN 14862) from the top, bottom, and sides which secure
the panel/chassis assembly to the enclosure. Also, align the mounting holes and install the three screws
(PN 14862) from the rear of unit which will secure the enclosure to the output (test) port/AC input/input
port panel.
4.2.2 Accumulator, Intensifier & Orion 3A (PN 55287) Removal
Tools required:
• Phillips screwdriver
• 11/32" wrench or nutdriver
• .061" hex wrench
• adjusting screwdriver (small flat blade)
• 11/32" open end wrench (thin)
• 7/16" open end wrench
Note

See Table 4-2 on page 22 and Figure 4.3 on page 22 for additional
Orion 3A parts information.
1. Vent the system to its atmosphere before attempting to work on the unit. Disconnect the power cord from
the power source.
2. Remove the front panel from its enclosure as described in Section 4.2.1 and carefully set on a bench top.
3. Using a 7/16" wrench, remove the following tubing sections:
• Accumulator to supply pressure gauge (1/8" dia.)
• Accumulator to pressure inlet on Orion 3A manifold (1/8" dia.)
• Accumulator to intensifier outlet (1/4" dia.)
4. Loosen and remove the six screws securing the two clamps that hold the intensifier and accumulator.
