Page 38/67 GEO T RIGGING PROCEDURE
• Rotate the fingerwheel clockwise until the chain is taught.
• Make a final check that the LEVA1500 chain is correctly installed and store the surplus chain in
the chain bag supplied. The chain bag should be clipped to the Chain Lever Hoist.
• Unse the LEVA1500 lever to apply the pull-up force to the bottom of the array. Notice that, as the
LEVA1500 chain gets shorter, the cabinets in the array close together to the angles set by the
linking bar adjustments.
• When all of the cabinets are closed together, required force to rotate LEVA1500 lever becomes
much stronger. This is the indication that the angles have been correctly set.
IMPORTANT
DO NOT attempt to force on LEVA1500 lever once you feel it resisting strongly to
rotation; you might damage GEOT flying system by doing so
IMPORTANT
DO NOT attempt to make any changes to the linking bars when the rear pull-up force is
applied.
1 2
3 4
