Nexo GEO T User Manual
Page 14

Page 14/67
GEO
T
G
ENERAL
S
ET
-
UP
I
NSTRUCTIONS
• CD18 rear: 1 amplifier in stereo mode, 2 CD18 rear per amplifier channel, mode switch in Stereo
position, Gain switch in 26 B gain position, all dynamic or filter processing switches off.
• CD18 front: 1 amplifier in stereo mode, 2 CD18 front per amplifier channel, mode switch in
Stereo position, Gain switch in 26 B gain position, all dynamic or filter processing switches off.
Which gives a total of 7 identical amplifiers for such a cluster.
IMPORTANT
Former NX241 TDcontroller GEO T presets Gain structure has changed from load 2.13 to
load 2.14.
•
Loads 2.13 and below: the NX242 expects all amplifiers to have the same overall
gain; add 6 dB gain to the HF section to compensate for LF rear and LF/MF rear
sections bridge operating mode 6 dB gain.
•
Loads 2.14 and above: all amplifier gain switches should be set at 26 dB (as in the
example above); the NX242 compensates for the bridge operating mode 6 dB
voltage gain on LF rear and LF/MF front sections.
