3-3 IM WX1-02E
Deta
led Descr
pt
on of Funct
ons
1
2
3
Index
Port Settngs
GateDX-P uses the following ports.
• Montor Server Port
The TCP/IP port number used for communication with DAQLOGGER or Remote
Monitor.
Runnng/Stoppng the Executable Functon
The user interface allows you to start and stop the executable function.
The executable function runs under one of the following two methods or “types.”
• Process Run/Stop
The executable function is run/stopped as a process.
• Service Run/Stop
The executable function is registered as an automatically executing service, then
run. After an executable function running as a service is stopped, its registration as
a service is deleted. As indicated by the service execution status, the executable
function continues processing even when the user has logged off of Windows.
Also, the software is automatically run as a service when the computer is turned
ON. Service execution can only be specified by users with Administrator privileges.
Services cannot be executed when using Windows Vista.
Montor Server Functon of the Executable Functon
When the executable function is running, you can connect from DAQLOGGER or
Remote Monitor via Ethernet using the remote monitor protocol, and acquire data. In this
case, system numbers are assigned as follows:
DX100P/DX200P assigned to Recorder1: system number 0
DX100P/DX200P assigned to Recorder2: system number 1
Executable Functon Status Dsplay
The user interface allows you to display status items for the executable function.
The information that can be displayed is as follows:
• Practice status (stopped, running as a service, running as a process)
• Connection status from the client
Displays a list of PCs running DAQLOGGERS and Remote Monitors with which the
executable software has opened a connection.
Group and Channel Assgnments
When connected to GateDX-P using Remote Monitor, the initial status of group and
channel assignments are as follows:
Group Name Waveform Number Channel Assgnment
Group 1 Measure Ch W01 CH01
••• •••
W30 CH30
Group 2 Math Ch W01 CH31
••• •••
W30 CH60
Note
When connecting DAQLOGGER to Gate-DXP, group and waveform assignments are ignored.
3.2 Detaled Descrpton of Functons
