2-8 IM WX1-02E
2.5 Vewng the Status of the Executable Functon
Procedure
Dsplayng the Connecton Status
1. Click the Execution/Status tab, or choose Vew > Executon/Status from the
menu bar.
The Execution/Status tab is displayed, allowing you to see the method under
which the executable function may be running (as a process or as a service),
whether or not it is running, and with which PCs communications are open.
Displays the names
of connected clients
Double-click to
display the Error
Indicator dialog box
Select the
practice type
Displays the communications status with the client
Gray: Stopped
Red: Error
Green: Normal
Vewng Error Detal
2. Double-click the box displaying the client communication status on the Execution/
Status tab (shown above).
The Error Indicator dialog box opens.
See section 3.3 for error messages.
Note
• If a warning message is displayed (code Wxxxx), the lamp that displays the connection
status by color does not blink red.
• When an error occurs and the lamp blinks red, the Error Indicator dialog box appears. If you
close the dialog box, the lamp turns green.
