3-1 IM WX1-02E
Deta
led Descr
pt
on of Funct
ons
1
2
3
Index
Chapter 3 Detaled Descrpton of Functons
3.1 Overvew
Gate-DXP performs Ethernet communications with the DX100P/DX200P and acquires
data at regular intervals. Through the monitor server function, the acquired data is
transferred to DAQLOGGER or Remote Monitor via Ethernet.
The following is a list of the features of each software function.
Envronment Settng Functons
Environment setting functions are used to enter all environment settings required to run
the executable function.
• Seral Port Settngs (as Needed)
Port
Type (RS-422A/485 or RS-232-C)
Baud rate
Parity
• Recorder Settngs
Port
Address
User name
User ID
Password
Automatic model determination
• Scan Interval Settngs
Scan interval setting for each recorder (0.5 to 3600 sec.)
Communication retry ON and OFF
Retry interval
• Port Settngs
Port number for monitor server
Port number for getting status
• Executable Functon Start/Stop
Runs as a service
Runs as a process
• Executable Functon Status Dsplay
Practice status display (stopped, running as a service, running as a process)
Display of the connection status from the client
Executable Functon
Features of the executable function are as follows:
• Running as a process and as a service is possible.
• Instantaneous data values are acquired from up to 16 DX100p/DX200Ps at regular
intervals.
• Runs as a monitor server via Ethernet if DAQLOGGER or Remote Monitor is the
client.
