Page 13
2-3
IM WX1-02E
1
2
3
Index
Operat
on Procedure
2.2 Enterng Envronment Settngs
Port Settngs
2.
Enter the port and address.
Port:
Select the port to be used for the connection. Only the numbered COM
ports turned ON in the license setting tab are displayed.
For Ports Set to Ethernet
Click a cell in the address column to open the dialog box in the figure below.
Enter the following settings.
IP address or host name: enter the IP address or host name of the DX100P/
DX200P to which you wish to connect.
User name:
enter the user name specified on the DX100P/DX200P to which
you wish to connect.
User ID:
enter the user ID specified on the DX100P/DX200P to which
you wish to connect.
Password:
enter the password specified on the DX100P/DX200P to which
you wish to connect.
Note
When logging on to the DX100P/DX200P from GateDX-P, the default password for the
DX100P/DX200P cannot be used. If it is used, login will fail.
For Ports Set to COM
Click a cell in the address column to open the dialog box in the figure below.
Select an RS-422-A address.
Address: only valid for COM ports using Ethernet or RS-422-A/485.
