Yokogawa ISC40 Inductive Conductivity Sensor - Manual (Page 29)

IM 12D8J2-E-E
29
10.5 Spareparts ISC40FF
Options ISC40FF Flow fitting, flange adapters
Part no. Description Process connection Material O-ring(s)
K1521AL /FF1 DN15 PN10 PVDF Viton
K1521AP /FF2 DN25 PN10 PVDF Viton
K1521AE /FF3 ANSI ½” – 150 lbs PVDF Viton
K1521AH /FF4 ANSI 1” – 150 lbs PVDF Viton
K1521AM /FP1 DN15 PN10 PP Viton
K1521AQ /FP2 DN25 PN10 PP Viton
K1521AF /FP3 ANSI ½” – 150 lbs PP Viton
K1521AJ /FP4 ANSI 1” – 150 lbs PP Viton
K1521AK /FS1 DN15 PN10 AISI 316 SS Viton
K1521AN /FS2 DN25 PN10 AISI 316 SS Viton
K1521AD /FS3 ANSI ½” – 150 lbs AISI 316 SS Viton
K1521AG /FS4 ANSI 1” – 150 lbs AISI 316 SS Viton
Note: Other O-ring materials are available as sparepart
Parts ISC40FF Flow fitting
Part no. Description Dimensions Material O-ring
K1541KD Holder + O-rings 2” PVDF Viton
K1541KL Holder + O-rings 2” Polypropylene Viton
K1541KA Holder + O-rings 2” AISI 316 SS Viton
Note: Other O-ring materials are available as sparepart
O-rings ISC40FF Flow fitting
Part no. Description Dimensions Material Quantity
O-rings -SA
K1500DB O-ring set 40.64 x 5.33; 26.57 x 3.53; Ring DN50 EPDM 5 sets
K1500DA O-ring set 40.64 x 5.33; 26.57 x 3.53; Ring DN50 Viton 5 sets
K1500DC O-ring set 40.64 x 5.33; 26.57 x 3.53; Ring DN50 Silicon 5 sets
K1500CD O-ring 40.64 x 5.33 Kalrez 1
K1500CH O-ring 26.57 x 3.53 Kalrez 1
K1500DD O-ring 53.34 x 5.33 Kalrez 1
O-rings -PA, -FA
K1500DF O-ring set 40.64 x 5.33; 26.57 x 3.53; 56.52 x 5.33 EPDM 5 sets
K1500DE O-ring set 40.64 x 5.33; 26.57 x 3.53; 56.52 x 5.33 Viton 5 sets
K1500DG O-ring set 40.64 x 5.33; 26.57 x 3.53; 56.52 x 5.33 Silicon 5 sets
K1500CD O-ring 40.64 x 5.33 Kalrez 1
K1500CH O-ring 26.57 x 3.53 Kalrez 1
K1500DH O-ring 56.52 x 5.33 Kalrez 1
Note: O-ring 53.34 x 5.33 (K1500DD) is used as a Kalrez replacement for the Ring DN50.
