IM 01C22K01-01E

4-3

4. INSTALLATION

4.4 Changing the Direction of

Integral Indicator

IMPORTANT

Always turn OFF power, release pressure and
remove a transmitter to non-hazardous area
before disassembling and reassmbling an
indicator.

An integral indicator can be installed in the following
three directions. Follow the instructions in section 9.4
for removing and attaching the integral indicator.

F0404.EPS

Figure 4.4

Integral Indicator Direction
