STEPS:

1. Prepare the clamps for the OMI by inserting the screws into the

clamp as shown above. Position the screws so that the ends don’t
protrude through the clamp’s hole.

2. Set the OMI in the panel cutout and hold it in place until all

clamps are in position.

3. Tighten the screw clamps in an even pattern until all are

uniformly snug.

Caution: Do not over-tighten the screws beyond snugness or

you may damage the housing.

Mounting Clamp Placement

Model

Left

Side

Right

Side

Top

Bottom

Supplied

OMI5070B-CE

1

1

2

2

6

OMI5121A-CE

3

3

3

3

12

OMI5150A-CE

2

2

3

3

10

REINSTALLATION: If, at anytime, you are required to reinstall an
OMI into a panel, be aware that the gasket will take a ‘set’ to the panel
and may no longer provide an adequate NEMA 4 seal Therefore, for best
results, we recommend that you replace the gasket if reinstallation is
required.

Configuration Wiring
To install application software and upload/download files on your OMI,
you may wish to connect your computer to the Open HMI. Connection
can be done via the serial port, USB port or the Ethernet port.

USB
To transfer files via the USB client port on the OMI, you must purchase
a USB download cable (Maple P/N 7431-0115). You must also install a
USB device driver onto your computer that supports connection to the
OMI. Please follow the instructions located in your OMI5000
Operations Manual (Windows CE Embedded 6.0 Professional Edition)
[Maple P/N 1010-1016] to install the USB driver onto your computer.
