Version 4.2/April 2005 Page 25
PCXZinstall
System Installation
Dispenser & Reader Specific Installation
Kraus Electronic Dispenser
Note all warnings at the beginning of installation section.
Instructions for DBox installations in this manual are for the specific DBoxes supplied by dispenser manufacturers. If using DBoxes
supplied by Progressive International, refer to the Installation Guide which accompanies PIE’s DBox.
The following Kraus models must have the minimum version of software noted to work properly with
Progressive equipment:
Micon 100
152 printed circuit board
versions 3.1 & 3.2
252 printed circuit board version 6.30
463 PLCC processor version 7.03
Micon 200 version 1.09
Micon 300 version 2.04
Micon 500 to be announced
Following instructions on preceding pages of installation section of this manual, install PCXZ and
configurator box(es). Then, follow specific instructions for connecting PCXZ system to the appropriate
Kraus DBox.
1. Connect the data communication wires from the Kraus dispenser into the dispenser
connectors on the PIE Kraus Configurator board. See Diagram: PCXZ to Kraus Electronic Dispensers which
follows. Note that there are three data communication wires connecting to a Kraus dispenser.
They are labeled as follows:
TTC Talk to Console/Kraus dispenser transmit data
TTP Talk to Dispenser/Kraus dispenser receive data
DDC Data Common / Kraus dispenser ground
2. Note the layout of the Kraus dispenser head. Refer to Diagram: Kraus Dispenser Head Layout.
3. If submerged turbine dispensers are used, install according to Kraus dispenser installation
instructions or install optional PIE relay control box. See Diagram: Kraus Turbine Dispenser Layout at end of
this section.
