Progressive International Electronics PCXZ
Version 4.2/April 2005 Page 6
PCXZinstall
System Installation
Dispenser & Reader Specific Installation
Gilbarco Electronic Dispenser
Note all warnings at the beginning of installation section.
Instructions for DBox installations in this manual are for the specific DBoxes supplied by dispenser manufacturers. If using DBoxes
supplied by Progressive International, refer to the Installation Guide which accompanies PIE’s DBox.
PIE ships current loop configurators as standard equipment. Some Gilbarco DBoxes are configured for RS422 operation. If the RS422
DBox cannot be converted to current loop operation, you must use an RS422 configurator and cables. Contact your PIE dealer to order.
Following instructions on preceding pages of installation section of this manual, mount PCXZ and
configurator box(es). Then, follow specific instructions for connecting PCXZ system to the appropriate
Gilbarco distribution box (DBox). Gilbarco DBoxes are listed on the following page.
1. Disconnect the Gilbarco console from the distribution box and connect the Gilbarco style
configurator box to the Gilbarco DBox using the appropriate cable supplied by PIE. Refer to
Diagram: PCXZ to Gilbarco Electronic Dispenser following this section.
2. Return to the PCXZ Installation Section for remaining system installation procedures.
Note: All Single Product Dispensers (SPDs) must be set for grade 1.
Listing: Gilbarco DBoxes
G ilbarco DBox Part # Description
PA01330000 Old Style with DIN connector
PA0261X000010 Universal Style with 1 board current loop
PA0261X000020 Universal Style with 2 boards current loop
PA0261X000011 Universal Style with 1 board RS422
PA0261X000021 Universal Style with 2 boards RS422
PA0306X010 Gsite Style with 1 board RJ45 connector
PA0306X020 Gsite style with 2 boards RJ45 connector
PA0242 TS1000 Style
