SaltDogg TGS06 Salt Spreader - Manual (Page 5)

5
TM
26
36
33
5. Install Spreader Assembly to Vehicle
Refer to Fig. 5
• Lift and align the spreader so that the adjuster hitch aligns
with the hitch receiver. Allow spreader to rest on hitch
receiver and bumper of vehicle. It may be necessary for two
people to perform the lifting of the spreader.
Fig. 5
Fig. 6
6. Install Stake Pocket Straps Refer to Fig. 6
• Insert (2) stake pocket straps 26 into holes located in
spreader.
• Rotate straps until aligned with empty holes on stake
pocket covers. You may need to pull the spreader towards
the tailgate to align straps to the best suited hole.
• Insert (2) 3/8"-16 x 2½" bolts 36 and (2) spacers 33 as
shown.
• Hand tighten hardware only.
• Adjust spreader location for best fit. Tighten all hardware.
Check all fasteners periodically to ensure they are tight.
