SaltDogg TGS06 Salt Spreader - Manual (Page 4)

4
TM
36
32
35
34
3. Assemble Stake Pocket Mounts Refer to Fig. 3
• Assemble two stake pocket mounts as shown using (1)
cover plate 32, (1) retainer nut plate 34, (1) retainer plate 35,
and (1) 3/8"-16 x 2½" bolt 36.
• Insure “U” portion of retainer plate is facing up, or towards
cover plate.
• Thread bolt into retainer nut plate using 2-2½ turns. This
bolt will be tightened once inserted into stake pocket
of truck.
Fig. 3
4. Insert Stake Pocket Mounts Refer to Fig. 4
• Install assemblies into stake pockets with the empty holes
towards the tailgate of the vehicle.
Fig. 4
• Insure “U” portion of the retainer plate securely engages
sheet metal of truck bed.
• Hand tighten hardware only.
