MANUAL
REWIND HOSE REEL
FOR 50' OR 75' X 1-1/2" ID
HOSE CONVEYING 125 GPM OF
AFFF PER MIL-F-24385
A
T
175 PSI
USE 24414-V
-50 FOR 50' OF HOSE, HOSE
ASSEMBL
Y
360700-50
USE 24414-V
-75 FOR 75' OF HOSE, HOSE
ASSEMBL
Y
360700-75
MARKING FOR SHIPMENT
PER MIL-STD-129 REQUIRED
REEL
SHALL
BE IN
ACCORDANCE WITH MIL-R-24414D(SH) LA
TEST
REVISION
T
OLERANCE ±1/16 UNLESS OTHER
WISE SPECIFIED
PROTECT
MACHINED CONNECTING SURF
ACES
FROM P
AINT
AND DURING SHIPPING
AND HANDLING
HOSE REEL
T
O
BE P
AINTED RED (1
1
105) "R" OR GREEN (14062) "G" PER FED-STD-595
(3600-29-13-15RR OR 3600-29-13-15RG) MARKING PER MIL-STD-130 REQUIRED
NOTE: -RIGHT
HAND
T
O
P
WIND SHOWN. FOR RIGHT
HAND BOTT
OM WIND, ROT
A
TE GOOSNECK 180°
-ALL
THREADED BOL
TS MUST
THREAD P
AST
THE NYLON NUT
BY
A
T
LEAST
1 FULL
THREAD,
BUT
NOT
MORE
THAN 5 FULL
THREADS. IF
THE BOL
T
LENGTH DOES NOT
MEET
THIS
REQUIREMENT
, SUBSITUTE WITH
A
LONGER OR SHOR
TER BOL
T
AS NEEDED. MAKE
ANY
INVENT
OR
Y
ADJUSTMENTS FOR
THIS SUBSITUTION.
ANY
DEVIA
TIONS MUST
BE
APPROVED BY
THE RESPONSIBLE GOVERNMENT
DOCUMENT
A
TION ENGINEER.
NOT
SHOWN FOR CLARITY
-HOSE
ASSEMBL
Y
(360700-50) or (360700-75)
-NOZZLE (SFL-GN-125)
7.625
REF
4.715
R
EF
6.375
REF
13.312
REF
11.652
REF
20.812
R
EF
1.094
REF
6.750
REF
.782
REF
33.338
REF
.938
R
EF
31.220
REF
46.603
REF
26.044
REF
'XX'
'ZZ'
'YY'
THIS DOCUMENT CONTAINS PROPRIETARY
INFORMATION OF REELCRAFT IND., INC. AND IT SHALL NOT BE DISCLOSED TO OTHERS OR DUPLICATED OR USED FOR
OTHERS WITHOUT THE EXPRESS WRITTEN
CONSENT OF REELCRAFT IND., INC.
WEIGHT TABLE AND CENTER OF GRAVITY
ITEM
M
ASS
'XX'
'YY'
'ZZ'
HOSE REEL WITH ROLLER GUIDE ONLY
168 lbs
6.92 in
14.69 in
3.84 in
COMPLETE SYSTEM (EMPTY) - 50 FT.
221 lbs
7.07 in
14.89 in
3.98 in
COMPLETE SYSTEM (FILLED WITH AFFF) - 50 FT.
258 lbs
7.17 in
14.85 in
4.09 in
COMPLETE SYSTEM (EMPTY) - 75 FT.
246 lbs
7.07 in
14.89 in
3.98 in
COMPLETE SYSTEM (FILLED WITH AFFF) - 75 FT.
276 lbs
7.17 in
14.85 in
4.09 in
DRAWING NO.
DRAWING TITLE:
DATE:
12/04/08
DRAWING NOT
TO SCALE
3600-29-13-15RR w/ 340307-5
(24414-V-50 OR 24414-V-75)
SINGLE AGENT HOSE REEL W/ HOSE GUIDE
TYPE V, GROUP A
11575 12/04/08
DATE DESCRIPTION
FOR REFERENCE ONLY
LTR
A1
ECN # CUSTOMER APPROVAL: DRAWN BY:
BDH
ENG APPROVAL: MFG APPROVAL:
X ELW
Form# Rev:
