REEL ASSEMBLY WITH HOSE GUIDE
ITEM NUMBER
P
ART NUMBER
DESCRIPTION
QUANTITY
1
3600-29-13-15RR
SINGLE AGENT HOSE REEL
1
2
340307-5
HOSE GUIDE ASSEMBLY
1
3
S81-6
NUT, NYLOC
6
4
S
110-6
WASHER, FLAT
6
5
S
56-67
HEX CAP SCREW 3/8-16 X 1 1/2"
2
6
S
56-68
HEX CAP SCREW 3/8-16 X 1 3/4"
4
1
2
3
4
4
5
6
INCLUDED BUT
NOT
SHOWN:
-(1) 360600-4 STRAP
AND BRACKET
ASSEMBL
Y
-(2) S362-12 SCREW
,
TRUSS HEAD 3/8-16 X 1" - 316 ST
AINLESS
-(2) S47-64 SCREW
, SET
3/8-16 X 3/8" - 316 ST
AINLESS
NOTE: -FOR RED P
AINT
DROP
-XX, FOR GREEN P
AINT
ADD -58
IN PLACE OF -XX -ALL
THREADED BOL
TS MUST
THREAD P
AST
THE
NYLON NUT
BY
A
T
LEAST
1 FULL
THREAD, BUT
NOT
MORE
THAN 5 FULL
THREADS. IF
THE BOL
T
LENGTH DOES NOT
MEET
THIS REQUIREMENT
,
SUBSITUTE WITH
A
LONGER OR SHOR
TER BOL
T
AS NEEDED. MAKE
ANY
INVENT
OR
Y
ADJUSTMENTS FOR
THIS SUBSITUTION.
ANY
DEVIA
TIONS MUST
BE
APPROVED BY
THE
RESPONSIBLE GOVERNMENT
DOCUMENT
A
TION
ENGINEER. THIS DOCUMENT CONTAINS PROPRIETARY
INFORMATION OF REELCRAFT IND., INC. AND IT SHALL NOT BE DISCLOSED TO OTHERS OR DUPLICATED OR USED FOR OTHERS WITHOUT THE EXPRESS WRITTEN
CONSENT OF REELCRAFT IND., INC.
Wind Things Up With Reelcraft
R DRAWING NO.
DRAWING TITLE:
DATE:
12/04/08
DRAWING NOT
TO SCALE
3600-29-13-15RR w/ 340307-5
(24414-V-50 OR 24414-V-75)
SINGLE AGENT HOSE REEL W/ HOSE GUIDE
TYPE V, GROUP A
11575 12/04/08
