Reelcraft AFFF Hose Reels MIL-R-24414-V-75 - Manual (Page 15)

Item
Number*
Manufacturer's
Part Number
Description
Onboard spare parts proposal
Onshore spare parts proposal
Required Storage
Space
1
327600-4
Bearing
1
110x110x100mm
2
327600-1
Swivel, Bearing Sleeve
1
130x130x150mm
3
S211-332
O-Ring, 2-3/8" X 2-3/4" X 3/16"
6
1
2
65x65x5mm
4
S211-331
O-Ring, 2-1/4" X 2-5/8" X 3/16"
2
4
65x65x5mm
5
390305
Internal retaining Ring, 1-1/8" X .037"TK
2
4
70x70x2mm
7
327600-5
Swivel, Spindle
1
125x125x250mm
8
327600-3
Elbow, Discharge
1
120x90x45mm
9
327600-2
Swivel, Outlet 2"
1
100x130x150mm
10
323600-3
Crown Gear
1
350x350x50mm
11
S200-230
O-Ring, 2-1/2" X 2-3/4" X 1/8"
2
4
140x140x130mm
5
360600-2
Bearing Assembly
1
140x140x130mm
9
360600-6A
Hand Rewind Assembly
1
440x220x30mm
18
365600-1
Hand Crank
1
250x100x20mm
360600-4
Bracket & Nylon Strap
1
145x235x245mm
SFL-GN-95
Nozzle w/ Pistol Grip - 90 GPM @ 100 PSI
1
245x230x140mm
SFL-GN-125
Nozzle w/ Pistol Grip - 125 GPM @ 100 PSI
1
245x230x140mm
360700-50
Hose Assembly 1-1/2" X 50' (15m) w/ Couplings
1
1300x1300x200mm
360700-75
Hose Assembly 1-1/2" X 75' (23m) w/ Couplings
1
1300x1300x200mm
*Specify either hose reel or spindle assembly when referencing item number in appendix "D".
Provisioning Documentation Technical Data
The following is an on-board spare parts list recommended for vessels carrying 1-10 AFFF reels. For larger vessels, carrying
more than 10 reels, it is
recommended that these ratios be maintained (round all fractions of parts up).
Spindle Assembly
Reel Assembly
Reelcraft Industries, Inc. • (800) 444-3134 / (260) 248-8188 • Fax: (260) 248-2605
E-mail:
[email protected] • Internet: www
.reelcraft.com
APPENDIX
“G”
13
