Page 12
15
9
8
14
11
14
12
10
12
14
1
2
3
14
2
16
4
15
5
11
11
22
21
20
7
23
17
6
18
4
5
3
3
2
3
8
9
18
11
17
12
10
13
15
16
1
14
19
10
9
9
8
9
17
16
11
7
10
10
INCLUDED BUT
NOT
SHOWN:
-(1) 360600-4 STRAP
AND BRACKET
ASSEMBL
Y
-(2) S353-12 SCREW
,
TRUSS HEAD 3/8-16 X 1"
-(2) S37-446 SCREW
, SET
3/8-16 X 3/8"
NOTE:
-FOR RED P
A
INT
DROP
-XX, FOR GREEN P
A
INT
ADD -58
IN PLACE OF -XX
-ALL
THREADED BOL
T
S MUST
THREAD P
A
ST
THE
NYLON NUT
BY
A
T
LEAST
1 FULL
THREAD, BUT
NOT
MORE
THAN 5 FULL
THREADS. IF
THE BOL
T
LENGTH DOES NOT
MEET
THIS REQUIREMENT
,
SUBSITUTE WITH
A
LONGER OR SHOR
TER BOL
T
AS NEEDED. MAKE
ANY
INVENT
OR
Y
ADJUSTMENTS FOR
THIS SUBSITUTION.
ANY
DEVIA
TIONS MUST
BE
APPROVED BY
THE
RESPONSIBLE GOVERNMENT
DOCUMENT
A
TION
ENGINEER.
13
THIS DOCUMENT CONTAINS PROPRIETARY
INFORMATION OF REELCRAFT IND., INC.
AND IT SHALL NOT BE DISCLOSED TO
OTHERS OR DUPLICATED OR USED FOR
OTHERS WITHOUT THE EXPRESS WRITTEN
CONSENT OF REELCRAFT IND., INC.
REEL ASSEMBLY
ITEM NUMBER
PART NUMBER
DESCRIPTION
QUANTITY
1
390264-TEST
SPINDLE ASSEMBLY
1
2
323600-6
HEAD, 29" OD
2
3
363600-3
DRUM ASSEMBLY
1
4
323600-4
REAR COLLAR
1
5
360600-2
BEARING ASSEMBLY
1
6
363600-4
FRAME ASSEMBLY
1
7
323600-21
HANDWIND BRACKET
1
8
360600-6E
HAND REWIND ASSEMBLY
1
9
S110-6
F
LAT WASHER, .375 ID
14
10
S56-68
HEX CAP SCREW, 3/8-16 X 1 3/4"
9
11
S81-6
NUT, NYLOK 3/8-16
28
12
S56-67
HEX CAP SCREW, 3/8-16 X 1 1/2"
3
13
S56-69
HEX CAP SCREW, 3/8-16 X 2"
8
14
S81-6S
NUT, NYLOK 3/8-16 (SHORT)
7
15
S56-66
HEX CAP SCREW, 3/8-16 X 1 1/4"
8
16
S56-64
HEX CAP SCREW, 3/8-16 X 7/8"
12
17
365600-1
HAND CRANK
1
SPINDLE ASSEMBLY
ITEM NUMBER
PART NUMBER
DESCRIPTION
QUANTITY
1
327600-4
BEARING
1
2
327600-1
SWIVEL, BEARING SLEEVE
1
3
S
211-332
O RING
3
4
S
211-331
O RING
1
5
390305
SNAP RING
1
6
316258
GREASE FITTING 1/4-28 PLD
1
7
327600-5
SWIVEL, SPINDLE
1
8
323600-3
CROWN GEAR
1
9
327600-2
SWIVEL, OUTLET
1
10
325600-5
AXLE
1
11
S200-230
O RING
1
12
327600-3
ELBOW, DISCHARGE
1
13
S110-6
WASHER, FLAT .375" ID
6
14
S56-69
HEX CAP SCREW 3/8-16 X 2"
6
15
S81-6
N
UT, NYLOK 3/8
6
16
S56-59
HEX CAP SCREW 5/16-18 X 2"
1
17
S56-56
HEX CAP SCREW 5/16-18 X 1 1/4"
8
18
S81-5
N
UT, NYLOK 5/16
5
19
390746
CAP, PLASTIC
1
20
390747
COVER, PROTECTION
1
21
S339-616
WASHER, LOCK 3/8
3
22
S347-67
HEX CAP SCREW 3/8-16 X 1 1/2"
3
23
S338-6
NUT, HEX 3/8-16
3
DRAWING NO.
DRAWING TITLE:
DRAWING NOT
TO SCALE
3600-29-13-15RR
(24414-V-50 OR 24414-V-75)
SINGLE AGENT HOSE REEL
TYPE V, GROUP A
11273SUPP
6/11/08
DATE
DESCRIPTION
NEW RELEASE
LTR
A1
ECN #
DATE:
6/11/08
CUSTOMER APPROVAL:
DRAWN BY:
JLB
ENG APPROVAL:
MFG APPROVAL:
DWT
ELW
APPENDIX
“D”
10
