2.0 Technical Specifications
2.1 Description of Hose Reel
AFFF hose reel assembly for 50ft-75ft of 1-1/2 in I.D. hose as per MIL-R-24414D
2.2 Description of Manufacturer
Reelcraft Industries, Inc.
2842 E. Business Hwy. 30
Columbia City, IN 46725
1-800-444-3134
www.reelcraft.com
Cage Code: 52173
2.3 AFFF Hose Reel Assembly Identification:
Part Number: 24414-V-50 -OR- 24414-V-75
2.4 Characteristics
Length : 33.3” (46.6” with crank in rewind position)
Width : 26”
Height : 31.2”
Weight Hose reel ONLY : 119 lbs.
Hose reel and roller guide : 168 lbs.
Complete system 50 ft.EMPTY : 221 lbs.
Complete system 75 ft.EMPTY : 246 lbs.
Complete system 50 ft. FILLED : 258 lbs.
Complete system 75 ft. FILLED : 301 lbs.
Shipping weight complete 50 ft. (commercial packaging) : 256 lbs.
Shipping weight complete 75 ft. (commercial packaging) : 281 lbs.
Shipping weight complete 50 ft. (crated) : 344 lbs.
Shipping weight complete 75 ft. (crated) : 369 lbs.
Position of Hose : Top or bottom wind (specified at time of order)
Position of Inlet : 4 positions, @ 90 degrees (specified at time of order)
Position of Crank Rewind : 9 positions, @ 20 degrees (specified at time of order)
2.4.1 General Arrangement Drawing (see Appendix A)
2.5 Major Components of Hose Reel
