7-2
Off – operating normally with no clients connected.
Flashing rapidly – network not ready, no IP address assigned.
Note
During the power up process all three LEDs may flash on or off, however if all three LEDs are
flashing together followed by a short delay and the flash sequence repeated, this indicates a
Power On Self Test (POST) error. The number of rapid flashes indicates the actual error code.
Pin Outs for the IP SpeedDome Ultra 8
The following tables give the pin out information for connecting the supplied connectors to the
cabling.
3 wire 24VAC supply
RJ-45 Ethernet interface (with female to female adaptor)
Pin # Color Designation
1 Black 24Vac
2 Red Ground
3 White 24Vac
Pin # Ethernet 10BASE-T 100BASE-TX
1 Transmit -
2 Transmit +
3 Receive -
4 N/A
5 N/A
6 Receive +
7 N/A
8 N/A
