6-1
6 Restoring factory defaults
The IPSDU8 has two physical recessed buttons, a Reset button and a Restore button. Refer to
Figure 6-1 and Figure 7-1 for the location of the buttons. These buttons are only used during
installation and commissioning of the unit and during fault finding; they are not intended to be used
during normal operation when the camera is installed.
Both buttons have black caps on them. The Reset button is closer to the I/O board and the
Restore button is further from the I/O board.
Note
The restore procedure only resets the web configuration pages to default. To reset the SDU8 to
factory defaults follow the instructions in the SpeedDome
® Ultra 8 Camera Dome Operator’s
Guide, 8200-0600-01.
Figure 6-1 Reset and Restore buttons
Resetting the IPSDU8
The Reset button, when pressed, will restart the IPSDU8.
Note
Performing a reset will not change any saved configuration settings.
View of the board with dome removed
Restore
Button
Reset
Button
