1
RAMSEY WINCH MODEL H-930 DOW-LOK
PLEASE READ THIS MANUAL CAREFULLY
This manual contains useful ideas in obtaining the most efficient operation from your Ramsey
Winch, and safety procedures one needs to know before operating a Ramsey Winch.
WARRANTY INFORMATION
Ramsey Winches are designed and built to exacting specifications. Great care and skill go into every
winch we make. If the need should arise, warranty procedure is outlined on the back of your self-
addressed postage paid warranty card. Please read and fill out the enclosed warranty card and send
it to Ramsey Winch Company. If you have any problems with your winch, please follow instructions
for prompt service on all warranty claims. Refer to back page for limited warranty.
NOTE: The rated line pulls shown are for the winch only. Consult the wire rope manufacturer for wire rope ratings.
SPECIFICATIONS: CONFORMS TO SAE J706
Rated Line Pull 1st Layer
(lbs) .................................................... 30,000
(kgs) ................................................... 13,590
Gear Reduction: .................................................................................. 41:1
Shipping Weight H-930 .............................................. 515 lbs. (238 kgs)
Layer
of Cable 1 2 3 4
Rated Line Pull lbs 30,000 24,500 20,700 18,000
All Models kgs 13,590 11,090 9,370 8,150
*Cable capacity ft 25 65 105 155
All Models m 7 19 31 47
Line Speed
FPM 13 17.6 20 24
MPM 3.9 5.3 6 7.2
*These specifications are based on recommended cable of 3/4"
(19mm) 6x19 extra improved plow steel cable.
