Ramsey Winch ATV UNIVERSAL WIRELESS REMOTE FOR ATV WINCHES User Manual

Page 12

251204 WARN A2000 / SUPERWINCH X1, X2, X1F, X2F, EX1

NOTE: For clarification see wiring schematic on page 11.

1. Connect red wire to center spade.
2. Connect green wire to the toggle switch terminal in the “OUT”

position.

3. Connect the yellow wire to the toggle switch terminal in the “IN”

position.

1. Locate accessory wire on ATV ignition.

NOTE: Accessory wire should have 12 volts only when ignition key is
on.

2. Cut spade connector off and connect red wire from receiver to accessory

wire using supplied quick splice connector.

Wiring the Toggle Switch

Connecting the Power Lead

Installing the Antenna

NOTE: For clarification see wiring schematic on page 11.

1. Clean predetermined mounting surface with Isopropyl alcohol and

buff dry. (In ATVs without hoods the best place to mount the
antenna will be the underside of the ATV cowling in the highest
possible position.)

2. Remove backing from top side of double-stick tape and apply to

back side of pc board. Remove backing from other side of double-
stick tape and position pc board in center on top inside surface of
cowling or hood at the predetermined mounting location.

3. Remove backing from copper tape. Carefully affix tape to terminal

on right side of pc board and follow contour of inside of cowling.
DO NOT ALTER LENGTH OF THE TAPE. Repeat for left side.

4. Route coax cable up from receiver to antenna and plug in at pc

board.
