UNIVERSAL FLOOR SHIFT

CONVERSION KIT

#7666 & #7667

These instructions apply to the following MR. GASKET products:

INSTALLATION INSTRUCTIONS

WORK SAFELY

Perform this installation on a good, clean, level surface for
maximum safety and with the engine turned “OFF”.

Installation of this shifter requires working underneath the
vehicle. Raise vehicle by lifting at points specified by the
vehicle manufacturer. Place blocks or wedges in front of and
behind both rear wheels to prevent movement in either
direction. Support the vehicle with approved automotive
support stands or wheel ramps.

DO NOT USE A BUMPER JACK FOR SUPPORTING VEHICLE.

USE EXTREME CARE AND CAUTION WHEN WORKING
UNDERNEATH VEHICLE.

Never get near or under vehicle until you are confident that
it is safely supported and will not move or fall from its
raised position.

The following parts are included in this package:

7666

7667

Qty.

Part No.

Part No.

Description

1

97091037

9709137

Knob

1

501 0004

501 0025

Shifter Assembly

1

117 0001

117 0001

Bracket - Mounting

1

116 0001Z

116 0001Z

Brace - Stiffener

1

247 0005Z

247 0005Z

Support - Lower Mounting

1

247 0008Z

247 0008Z

Support - Extension (Optional Use)

1

247 0007Z

247 0007Z

Support - Upper (Optional Use)

1

247 0006Z

247 0006Z

Support - Lower (Optional Use)

2

105 0005Z

105 0005Z

Transmission Arm - For Milled Shafts

2

105 0004Z

105 0004Z

Transmission Arm - For Round Shafts

1

213 0002Z

213 0190Z

Linkage Rod

1

213 0003Z

213 0192Z

Linkage Rod

1

179 8805

179 8805

Jam Nut

1

154 0002

154 0176

Bagged Hardware

2

119 8057PO 119 8057PO

Rod Adjusting Button

1

425 0005PO

Coupling-Rod Extension

1

213 0209Z

Rod-Threaded

2

97X91028

97X91028

“U” Bolt

2

97090030

97090030

7/16-14 x 1 Hex Head Bolt

1

97090031

97090031

7/16-14 x 1-1/4 Hex Head Bolt

5

97000686

97000686

1/2" Flatwasher

3

97000404

97000404

7/16" Lockwasher

2

179 4343

179 4343

7/16-14 Hex Nut

3

97001805

97001805

5/16-24 x 1 Hex Head Bolt

3

96000559

96000559

5/16" Flatwasher

7

97000088

97000088

5/16-24 Hex Nut

7

97000089

97000089

5/16" Lockwasher

4

97000015

97000015

Spring Clip

4

97090079

97090079

#10-12 x 1 Pan Head Screw

1

114 8058

114 8058

Rubber Boot

1

195 2590

195 2590

Trim Plate

1

1540110

1540110

Hardware Kit

1

1010010

1010010

Ignition Block Adapter

1

1120007

1120007

Ignition Block

1

2280062

2280062

Spacer

2

2720008

2720008

Screw, 6-32 x 7/16

2

2720009

2720009

Screw, 6-32 x 5/8

SHIFTER INSTALLATION

1. Place factory shifter in NEUTRAL position. Disconnect and

remove stock linkage. Remove stock column shift lever by
driving pin out.

STEERING COLUMN LOCK-BACKDRIVE LINKAGE
MODIFICATION FOR 1969 & LATER VEHICLES.
Steering column lock activated by the shifting linkage must
be modified as follows: Secure the 1st/REVERSE lever
(located at the front of steering column, ahead of firewall in
engine compartment,) in its REVERSE position so it cannot
move. This will allow column to “LOCK” when the ignition
key is turned to the “OFF” position and withdraw freely out
of lock.
The SAFETY IGNITION BLOCK device supplied with this kit
MUST be installed as shown on page 4.
2. Remove Mr. Gasket shifter from mounting bracket. Be

careful when removing, as internal components of shifter
mechanism will become loose and may separate from
housing. Install bracket to transmission as shown.
NOTE: Three basic brackets (items 3, 4 & 5) are used in all
installations to mount the shifter. You may have to bend
or trim some of the brackets for clearance purposes and
to help ease assembly. Three optional pieces (items 6, 7 &
8) are used when it is necessary to clear obstructions on
trans-mission extension housing. Assemble using 5/16-24
X 1” hex head bolts, lockwashers and hex nuts supplied.
REFER TO FIG. 1.

Vehicles equipped with an Overdrive Transmission have
a cross-member support located underneath the floor-
board, this may interfere with the shifter installation. Cut
a section of the cross-member support out of floorboard
or trim the shifter mounting bracket for clearance.
Overdrive Transmission installations may require using
optional support pieces (items 6, 7 & 8).

7666

7667

Qty.

Part No.

Part No.

Description

7666 - Universal Floor Shift Conversion Kit, Fits Most

Rear-Wheel Drive Passenger Car Applications
With 3-Speed Manual Transmissions

7667 - Universal Floor Shift Conversion Kit, Fits Most

Pick-Up Truck Applications With 3-Speed Manual
Transmissions
