A-1
INSTALLATION FLEX FEED™ 74 HT
TECHNICAL SPECIFICATIONS – FLEX FEED™ 74 HT (K3883-XX)
TEMPERATURE RANGE
OPERATION: -40°F to 104°F (-40°C to 40°C)
STORAGE: -40°F to 122°F (-40°C to 50°C)
INPUT VOLTAGE and CURRENT
HEIGHT WIDTH DEPTH WEIGHT
Wire 11.1 Inches 13.6 Inches 13.3 Inches 36 lbs.
Drive ( 294mm) (345mm) (337mm) (16.3kg)
(only)
PHYSICAL DIMENSIONS
VOLTAGE
24 – 42 VAC
NOTES
Wire Drive
INPUT AMPERES
10A
RATED OUTPUT @ 104°F (40°C)
No Gouging Kit
With Gouging Kit
Wire Drive
Wire Drive
Gouging Stud
DUTY CYCLE
60%
60%
30%
INPUT AMPERES
600 Amps
500 Amps
600 Amps
GEARING - WIRE FEED SPEED RANGE-WIRE SIZE
WFS RANGE
50 – 500 inch/min
(1.3 – 12.7 m/min)
50 – 700 inch/min
(1.3 – 19.0 m/min)
.025” – 3/32”
(0.6 – 2.4 mm)
.025” – 1/16”
(0.9 – 1.6 mm)
.035” - .120”
(0.9 – 3.0 mm)
.035 – 5/64”
(0.9 – 2.0 mm)
PINION GEAR
20 tooth *
30 tooth
GMAW FCAW
Thermal tests have been performed at ambient temperature. The Duty Cycle (duty factor) @ 40ºC (104°F) has
been determined by simulation.
* = gearing installed in the wire drive as equipped from the factory.
WIRE SIZES
IP2X for the wire drive and user interface.
