Motor Bottom Support
L16384-1
1
X X X X
21B
Speed Nut (Not Shown)
T11525-8
4
X X X X
22
Motor & Gearbox Assembly
See P-747-E
1
X X X X
22A
Insulator
T11267-A
3
X X X X
22B
Insulator
T11267-B
3
X X X X
22C
Thread Forming Screw
S9225-66
3
X X X X
22D
Lock Washer (Not Shown)
E106A-2
3
X X X X
23
Thread Forming Screw (Not Shown)
S9225-99
4
X X X X
25A
Motor Top Support
L16384-2
1
X X X X
25B
Speed Nut (Not Shown)
T11525-8
2
X X X X
26A
Insulator
T11267-A
3
X X X X
26B
Insulator
T11267-B
3
X X X X
26C
Thread Forming Screw
S9225-66
3
X X X X
26D
Lock Washer
E106A-2
3
X X X X
27
Thread Forming Screw (Not Shown)
S9225-99
4
X X X X
28
Plug Button
T10397-19
2
X X X X
29A
Solenoid Valve
M17294-8
1
X X X X
29B
Plain Washer (Not Shown)
S9262-149
1
X X X X
29C
Conduit Lock Nut (Not Shown)
T14370-1
1
X X X X
30
Gas Hose (Not Shown)
T10642-265
1
X X X X
31
Hose Clamp (Not Shown)
T13777-8
2
X X X X
33
Bushing
T12380-3
1
X X X X
34
Plug Button
T10397-7
1
X X X X
40
Decal (M24809-3) (Part of M24809)
NSS
1
X X X X
41
Decal (M24809-4) (Part of M24809)
NSS
1
X X X X
42
Decal (M24809-5) (Part of M24809)
NSS
1
X X X X
43
Contactor Harness (Not Shown)
M24980
1
X X X X
