5.2.10 LED Indicator and Button Connector (JP2)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 PW_LED +5V 2 +5V
3 GND 4 HD_LED
5 SUS PW LED +5V 6 RST_SW
7 GND 8 GND
9 PW_BN 10 GND
2 10
y y y y y
y y y y y
1 9
Table 5-11: LED Indicator and Button Connector (JP2) Pinouts
5.2.11 LVDS Backlight Connector (INVERTER1)
5.2.12 MCU Connector (JP7)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 MCLR 2 +5V
3 +5V 4 MCU_IR
5 ICSPCLK 6 AUTO_CLK
7 ICSPDAT 8 AUTO_DATA
9 GND 10 GND
2 10
y y y y y
y y y y y
1 9
Table 5-13: MCU Connector (JP7) Pinouts
PIN NO. DESCRIPTION
1 +12V
2 +12V
3 BLON
4 BRIGHTNESS
5 GND
6 GND
Table 5-12: LVDS Backlight Connector (INVERTER1) Pinouts
