5.2.17 Touch Panel Connector (TS1)
5.2.18 TTL Panel Connector (CN7)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 21 TFT_G5
2 GND 22 TFT_G4
3 TTL_VSYNC 23 TFT_G3
4 TTL_VCC3 24 GND
5 TTL_VCC3 25 TFT_G2
6 TTL_VCC3 26 TFT_G1
7 TTL_VCC3 27 TFT_G0
8 TTL_HSYNC 28 GND
9 LCD_EN 29 TFT_R5
10 GND 30 TFT_R4
11 GND 31 TFT_R3
12 GND 32 GND
13 TFT_B5 33 TFT_R2
14 TFT_B4 34 TFT_R1
15 TFT_B3 35 TFT_R0
16 GND 36 GND
PIN NO. 8-Wire 4-Wire 5-Wire
1 Right Sense N/A N/A
2 Left Sense N/A N/A
3 Bottom Sense N/A N/A
4 Top Sense N/A Sense (S)
5 Right Excite Right LR (X)
6 Left Excite Left LL (L)
7 Bottom Excite Bottom UR (Y)
8 Top Excite Top UL (Y)
9 GND GND GND
Table 5-18: Touch Panel Connector (TS1) Pinouts
