AFL-08B-N270 User Manual
Page 89
ƒ 800x600 18b
ƒ 1024x768 18b
ƒ 1280x1024 36b
ƒ 1400x1050 36b
ƒ 1440x900 36b
ƒ 1600x1200 36b
ƒ 1024x600 18b
ƒ by H/W
Î LFP Current Jumper Setting [1024x600 18b]
Displays the resolution setting of the LFP port by the on-board jumper.
4.7.2 South Bridge Configuration
The South Bridge Configuration menu the Southbridge chipset to be configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
South Bridge Chipset Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Audio Controller
[Auto]
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 19:South Bridge Chipset Configuration
Î Audio Controller [Auto]
Use the Audio Controller option to enable or disable the onboard audio.
Î
Auto D EFAULT
The audio chip is activated if detected
Î
All Disabled The audio chip is disabled
